IRS26302DJ
Lead Definitions
Symbol
V SDC
GF
V DC
HIN1,2,3
LIN1,2,3
P FCTRIP/ /B RTRIP
P FCOUT /B ROUT
P FCIN /B RIN
FAULT/EN
ITRIP
RCIN
V SS
COM
LO1,2,3
V CC
V S1,2,3
HO1,2,3
V B1,2,3
www.irf.com
Description
GF supply return
GF analog input for DC + overcurrent shutdown. When active, GF shuts down outputs and
activates FAULT and RCIN low. When GF becomes inactive, FAULT stays active low for an
externally set time t FLTCLR , then automatically becomes inactive (open-drain high impedance).
GF comparator supply (DC bus)
Logic inputs for high side gate driver outputs (HO1,2,3), in phase
Logic input for low side gate driver outputs (LO1,2,3), in phase
Analog input for PCF overcurrent shutdown. When active, GF shuts down outputs and activates
FAULT and RCIN low. When P FCTRIP/ /B RTRIP becomes inactive, FAULT stays active low for an
externally set time t FLTCLR , then automatically becomes inactive (open-drain high impedance).
PFC/Brake output
Input, PFC/Brake, active high
Open Drain and input, act high
Analog input for DC – over-current shutdown. When active, ITRIP shuts down outputs and
activates FAULT and RCIN low. When ITRIP becomes inactive, FAULT stays active low for an
externally set time t FLTCLR , then automatically becomes inactive (open-drain high impedance).
An external RC network input used to define the FAULT CLEAR delay (t FLTCLR ) approximately
equal to R*C. When RCIN > 8 V, the FAULT pin goes back into an open-drain high-impedance
state.
Logic ground
Power ground & Analog input (ITRIP)
Low side driver outputs
Low side supply voltage
High voltage floating supply return
High side driver outputs
High side floating supply
? 2009 International Rectifier
14
